Product Description

The Merican M-MB Red Light Therapy Bed is a professional full-body photobiomodulation system designed to deliver therapeutic red and near-infrared light in a comfortable, user-friendly format suitable for wellness centers, spas, clinics, and luxury home environments. Built by Merican—an experienced manufacturer of LED therapy beds with decades of industry expertise—this model balances advanced performance with approachable design and intuitive controls.

At its core, the M-MB bed uses 26,880 high-output LED chips with a long 100,000-hour lifespan, delivering a blend of red (633 nm & 660 nm) and near-infrared (810 nm, 850 nm, 940 nm) wavelengths with independent control over each band. This multi-wavelength spectrum enables deep tissue penetration and can support a range of wellness goals including improved circulation, muscle recovery, skin health, reduced inflammation, and overall cellular rejuvenation.

Engineered for comfort and ease of use, the system features both continuous and pulsed operating modes, allowing customizable treatment delivery based on individual needs. A wireless tablet and integrated LCD touchscreen make operation simple, and built-in Bluetooth speakers enhance the session experience with music or ambient audio. Premium UK Lucite® acrylic panels provide up to 99 % light transmittance, ensuring efficient light delivery to the body. With smooth opening mechanisms, thoughtful ergonomics, and robust industrial construction, the M-MB offers a compelling option for clinics or individuals seeking high-quality, full-body red light therapy.

Product Features

• Full-body red light therapy bed

• 26,880 high-output EPISTAR® LEDs with 100,000-hour lifespan

• Multi-wavelength therapy spectrum

  • Red: 633 nm, 660 nm

  • Near-Infrared: 810 nm, 850 nm, 940 nm

• Independent control of each wavelength

• High irradiance: ~75 mW/cm² at user level

• Continuous wave and pulse operating modes

• Recommended session time: 13–15 minutes

• Wireless tablet control + LCD touchscreen interface

• Premium UK Lucite® acrylic with up to 99% light transmittance

• Smooth opening mechanics with springs for ease of use

• Built-in Bluetooth speakers for audio playback

• Sleek white or black finish

• Designed for wellness centers, spas, clinics, and home use

Product Specifications

Light & Therapy

• LEDs: 26,880 EPISTAR® (100,000-hour lifespan)

• Wavelengths:

  • Red: 633 nm, 660 nm

  • Near-Infrared: 810 nm, 850 nm, 940 nm

  • Independent wavelength control

• Irradiance:

  • At LED level: 129 mW/cm²

  • At user level: ~75 mW/cm²

• Operating Modes: Continuous wave & pulse

Session & Power

• Recommended Session: 13–15 minutes

• Power Consumption: 4,500 W

• Voltage: 220 V

Control & Interface

• Control System: Wireless tablet + LCD touchscreen

Materials & Build

• Acrylic Panels: UK Lucite® with up to 99% light transmittance

• Opening Mechanism: Springs for easy lid opening

• Built-in Audio: Bluetooth speakers

• Finish: White / Black

Dimensions & Weight

• External Dimensions: 215 × 104 × 90 cm (85 × 41 × 35 in)

• Net Weight: 200 kg (441 lb)

• Gross Weight: 278 kg (613 lb)
